HI-END CD ,OJAČEVALEC,ZVOČNI

CONSONANCE FORBIDDEN

CITY, ORFEO-UPGRADED

DC 120 LINEAR CD PLAYER WITH MORE 16 BIT DAC CHIPS EQUIPED


Consonance Forbidden City-Orfeo, as the upgraded version of cd120liner should be the new type of CD player come into Forbidden City family.

The idea behind this CDE player was to enhance sound erformance of CF 120 linear by using advanced Linear technology and carefully selected compnents so as to further release the true possibility of 16bit/44 1kHz music.

 Features:
Linear technology applied in DAC stage, sampling frequency selected manually from 44.1 kH to 88.2kH by remote
4 pieces Philips TDA 1543 chip working in pacallei for lower output essential impedance and higher DAC precision
Heavier chassis, LED display, better power supply and compnents bring more detailed care to the sound
No smearing effect caused by digital filter, superb transient response without any over-shooting in sound
 Linear technology (applied to CD player):
Non-oversampling, no digital filter
J-FET/Transisters filter, no op-amp at all
Passive I/V conversion in progression
Short pass lenght, less number of parts
 Specifications:
DAC resolution 16bit TDA 1543x4
OdBF signal output 2.35V RMS
Output Terminals Gold plated Tube RCA unbalanced
Frequency response Less than +/- 0.5 dB deviation 20Hz-20kHz
Signal-to-noise ratio More than 100 dB
Crosstalk Less than – 100dB
Distorsion (RCA)Less than 0.12%
Remote Control Philips RC-5 compatible IR system 36KHz modulation frequency
Dimensions/Weight 11cmx45x33 cm (HxWxD)/18 kg

CONSONANCE FORBIDDEN

CITY. TRISTAN-COOL CLASS A SEDIGN, 100 WATT SOLID-STATE AMPLIFIER, MM/MC PHONO STAGE EQQUIPED


Consonance Forbidden City – Tritan, as a simplifier version of Calaf, should be the new member of Forbidden City family.

This solid – state amplifier also applied COOL Class A technology inherited from Calaf.

Combined the advantage of class AB and the class A technology, the Cool Class A technology actually achieved same linear Sound performnce essentially but without normaln need of big electrical current, as Slass A does.

With it 100 watt power output, Tristan fills the gap as well between a 100 linear and Calaf in solid state amplifier line of Consonance.

 100 watt output power
LED display equipped
Relay switched input source selector
Digitaly controlled active preamp stage
Cool Class A technology applied in amplifier stage
High quality MM/MC phone stage employed
 Powe output 100W+ 100W at 8 Ohms
Minimum load 4 ohms speakers can be connected
Input Sources 4 selectable inputs switched by gold plated relays
Input Terminals Gold plated Phone/RCA unbalanced
Phone input (MM/MC) selectable
Frequency response – 0.5 dB deviation 2Hz 80 kHz
Signal-to-noise ratio More than 95dB
Input Sensitivity 300 mV
Distortion Less than 0.02% (70W ohms)
Remote Control Phillips RC-5 compatible IR system 36kHz modulation frequency
Dimensions/Weight 11 cm x 43cm x 39 cm (HxWxD)/22 kg
